MacBook Pro 16-inch M1 Max Chip

Apple M1 Pro chip

• 10-core CPU with 8 performance cores and 2 efficiency cores

• 16-core GPU

• 16-core Neural Engine

• 200GB/s memory bandwidth

• Media engine

  • Hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW

  • Video decode engine

  • Video encode engine

  • ProRes encode and decode engine

• Configurable to:

  • M1 Max with 10-core CPU and 24-core GPU

  • M1 Max with 10-core CPU and 32-core GPU

Display

Liquid Retina XDR display

• 16.2-inch (diagonal) Liquid Retina XDR display;1 3456-by-2234 native resolution at 254 pixels per inch

XDR (Extreme Dynamic Range)

• 1,000,000:1 contrast ratio

• XDR brightness: 1000 nits sustained full-screen, 1600 nits peak2 (HDR content only)

• SDR brightness: 500 nits

Color

• 1 billion colors

• Wide color (P3)

• True Tone technology

Memory

Apple M1 Pro Chip

• 16GB unified memory

  • Configurable to 32GB (M1 Pro or M1 Max) or 64GB (M1 Max)

Battery and Power3

• Up to 17 hours Apple TV app movie playback

• Up to 11 hours wireless web

• 70-watt-hour lithium-polymer battery3

• 67W USB-C Power Adapter (included with M1 Pro with 8-core CPU)

• 96W USB-C Power Adapter (included with M1 Pro with 10-core CPU or M1 Max, configurable with M1 Pro with 8-core CPU)

• USB-C to MagSafe 3 Cable

• Fast-charge capable with 96W USB-C Power Adapter

Storage4

• 1TB SSD

Video Playback

• Supported formats include HEVC, H.264, and ProRes

• HDR with Dolby Vision, HDR10, and HLG

Audio Playback

• Supported formats include AAC, MP3, Apple Lossless, FLAC, Dolby Digital, Dolby Digital Plus, and Dolby Atmos

Keyboard and Trackpad

Backlit Magic Keyboard with:

• 78 (U.S.) or 79 (ISO) keys including 12 full-height function keys and 4 arrow keys in an inverted-T arrangement

• Touch ID

• Ambient light sensor

• Force Touch trackpad for precise cursor control and pressure-sensing capabilities; enables Force clicks, accelerators, pressure-sensitive drawing, and Multi-Touch gestures

Wireless

Wi-Fi

• 802.11ax Wi-Fi 6 wireless networking

• IEEE 802.11a/b/g/n/ac compatible

Bluetooth

• Bluetooth 5.0 wireless technology

Camera

• 1080p FaceTime HD camera

• Advanced image signal processor with computational video
