Philips - 45B1U6900CH/94

Technical Specifications

• Connectivity

  Signal Input

  HDMI 2.0 x 1, DisplayPort 1.2 x 1, USB-C x 1 (DisplayPort Alt mode, data and Power Delivery)

  Sync Input

  Separate Sync

  Audio (In/Out)

  Audio out

  HDCP

  HDCP 1.4 (HDMI / DisplayPort / USB-C), HDCP 2.2 (HDMI / DisplayPort / USB-C)

  USB Hub

  USB 3.2 Gen 1, USB-A downstream x 4 (with 1 fast charge B.C 1.2)

• Picture/Display

  Panel Size

  34 inch / 86.36 cm

  Aspect ratio

  21:9

  LCD panel type

  VA LCD

  Backlight type

  W-LED system

  Pixel pitch

  0.23175 x 0.23175 mm

  Brightness

  300  cd/m²

  Display colors

  16.7 M

  Color gamut (typical)

  NTSC 99.25%*, sRGB 123.24%*

  Contrast ratio (typical)

  3000:1

  SmartContrast

  Mega Infinity DCR

  Response time (typical)

  4 ms (Gray to Gray)*

  Viewing angle

  • 178º (H) / 178º (V)

  • @ C/R > 10

  Picture enhancement

  SmartImage game

  Maximum resolution

  3440 x 1440 @ 100 Hz*

  Effective viewing area

  797.22 (H) x 333.72 (V) - at a 1500R curvature*

  Scanning Frequency

  30 - 160 kHz (H) / 48 - 100 Hz (V)

  sRGB

  Yes

  Flicker-free

  Yes

  Pixel Density

  109.68 PPI

  LowBlue Mode

  Yes

  Display Screen Coating

  Anti-Glare, 3H, Haze 25%

  MPRT

  1 ms

  EasyRead

  Yes

  Adaptive sync

  Yes

• Power Delivery

  Max power delivery

  USB-C: Up to 65W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A)

  Version

  USB PD version 3.0

• Convenience

  Built-in Speakers

  5 W x 2

  Plug & Play Compatibility

  • DDC/CI

  • Mac OS X

  • sRGB

  • Windows 10 / 8.1 / 8 / 7

  User convenience

  • Power On/Off

  • Menu

  • Volume

  • Input

  • SmartImage Game

  OSD Languages

  • Brazil Portuguese

  • Czech

  • Dutch

  • English

  • Finnish

  • French

  • German

  • Greek

  • Hungarian

  • Italian

  • Japanese

  • Korean

  • Polish

  • Portuguese

  • Russian

  • Simplified Chinese

  • Spanish

  • Swedish

  • Traditional Chinese

  • Turkish

  • Ukrainian

  Other convenience

  • Kensington lock

  • VESA mount (100x100mm)

  MultiView

  • PIP/PBP mode

  • 2x devices

  Built-in webcam

  5.0 megapixel camera with microphone and LED indicator (for Windows Hello)

  Noise cancellation

  Yes

• Stand

  Height adjustment

  130  mm

  Tilt

  -5/20  degree

• Power

  Power supply

  • Internal

  • 100-240VAC, 50-60Hz

  Off mode

  0.3 W (typ.)

  On mode

  57.0 W (typ.)

  Standby mode

  0.5 W (typ.)

  Power LED indicator

  • Operation - White

  • Standby mode- White (blinking)

• Dimensions

  Product with stand (mm)

  808 x 557 x 281  mm

  Packaging in mm (WxHxD)

  980 x 519 x 226  mm

  Product without stand (mm)

  808 x 381 x 111  mm

• Weight

  Product with packaging (kg)

  12.43  kg

  Product with stand (kg)

  9.29  kg

  Product without stand (kg)

  7.16  kg

• Operating conditions

  Altitude

  Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

  Temperature range (operation)

  0 to 40  °C

  MTBF

  50,000 (excluding backlight)  hour(s)

  Relative humidity

  20%-80  %

  Temperature range (storage)

  -20 to 60  °C

• Sustainability

  Environmental and energy

  RoHS

  Recyclable packaging material

  100  %

  Specific Substances

  • Mercury free

  • PVC / BFR free housing

• Compliance and standards

  Regulatory Approvals

  • CB

  • CE Mark

  • CU-EAC

  • EAEU RoHS

  • FCC Class B

  • ICES-003

  • TUV/ISO9241-307

  • TUV-BAUART

• Cabinet

  Color

  Black

  Finish

  Textured
