Philips - 24B1D5600/94

Technical Specifications

• Picture/Display I

  Panel Size

  23.8 inch / 60.5 cm

  Monitor Panel Type

  IPS technology

  Brightness

  250  cd/m²

  Contrast ratio (typical)

  1000:1

  SmartContrast

  50,000,000:1

  Display colors

  16.7 M (6 bit + Hi FRC)

  Color gamut (typical)

  NTSC 99%*, sRGB 99.8%*

  Aspect ratio

  16:9

  Backlight type

  W-LED system

  Display Screen Coating

  Anti-Glare, 3H, Haze 25%

  EasyRead

  Yes

  Effective viewing area

  526.848 (H) x 296.352 (V) mm

  Flicker-free

  Yes

  LowBlue Mode

  Yes

  Maximum resolution

  2560 x 1440 @ 75 Hz*

  Picture enhancement

  SmartImage

  Pixel Density

  123 PPI

  Pixel pitch

  0.2058 x 0.2058 mm

  Scanning Frequency

  30 - 114 kHz (H) / 48 - 75 Hz (V)

  sRGB

  Yes

  Viewing angle

  178º (H) / 178º (V), @ C/R > 10

  Response time (typical)

  4 ms (Gray to Gray)*

• Picture/Display II

  Panel Size

  13.3 inch / 33.8 cm

  Monitor Panel Type

  EPD

  Aspect ratio

  3:4

  Display colors

  4 bits grey scale

  Display Screen Coating

  Anti-Glare, 3H, Haze 15%

  Effective viewing area

  278.4 (H) x 202.8 (V) mm

  Optimum resolution

  1200 x 1600

  Pixel Density

  150 PPI

  Pixel pitch

  0.169 x 0.169 mm

• Connectivity/Display I

  Audio (In/Out)

  Audio out

  HDCP

  HDCP 1.4 (DisplayPort / USB-C)

  RJ45

  Ethernet LAN up to 1G*, Wake on LAN

  Signal Input

  DisplayPort 1.2 x 1, USB-C x 1 (DP Alt mode, Power delivery)

  Sync Input

  Separate Sync

  USB Hub

  USB 3.2 Gen 2 / 10 Gbps, USB-C upstream x 1, USB-A downstream x 4 (with 1 fast charge B.C 1.2)

• Connectivity/Display II

  Audio (In/Out)

  Audio out

  HDCP

  HDCP 1.4 (USB-C)

  Signal Input

  USB-C x 1 (DP Alt Mode, Power delivery)

  Sync Input

  Separate Sync

• Power Delivery/Display I

  Max power delivery

  USB-C up to 90W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.5A)

  Version

  USB PD version 3.0

• Power Delivery/Display II

  USB-C (input)

  65W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A)

  USB-C (output)

  15W (5V/3A)

  Version

  USB PD version 3.0

• Convenience/Display I

  OSD Languages

  • Brazil Portuguese

  • Czech

  • Dutch

  • English

  • Finnish

  • French

  • German

  • Greek

  • Hungarian

  • Italian

  • Japanese

  • Korean

  • Polish

  • Portuguese

  • Russian

  • Simplified Chinese

  • Spanish

  • Swedish

  • Traditional Chinese

  • Turkish

  • Ukrainian

  Other convenience

  Kensington lock, VESA mount (100x100mm)

  Plug & Play Compatibility

  DDC/CI, Mac OS X, sRGB, Windows 11 / 10 / 8,1 / 8 / 7

  User convenience

  SmartImage, Input, Brightness, Menu, Power On/Off

  Control software

  SmartControl

• Convenience/Display II

  Other convenience

  Kensington lock, VESA mount (100x100mm), Front Light (White/Yellow)

  User convenience

  Clear, Front light, Mode, Level, Menu/Power

  OSD Languages

  • Brazil Portuguese

  • Czech

  • Dutch

  • English

  • Finnish

  • French

  • German

  • Greek

  • Hungarian

  • Italian

  • Japanese

  • Korean

  • Polish

  • Portuguese

  • Russian

  • Simplified Chinese

  • Spanish

  • Swedish

  • Traditional Chinese

  • Turkish

  • Ukrainian

  Plug & Play Compatibility

  DDC/CI, Mac OS X, sRGB, Windows 11 / 10 / 8,1 / 8 / 7

• Stand

  Height adjustment

  100  mm

  Swivel

  -/+45  degree

  Tilt

  -5/23  degree

• Power

  ECO mode

  18.5 W (typ.)

  Power supply

  • External

  • 100-240VAC, 50-60Hz

  Off mode

  0.3 W (typ.)

  On mode

  26 W (typ.)

  Standby mode

  0.3 W (typ.)

  Power LED indicator

  • Operation - White

  • Standby mode- White (blinking)

• Dimensions

  Packaging in mm (WxHxD)

  980 x 420 x 159  mm

  Product without stand (mm)

  787 x 323 x 46  mm

  Product with stand(max height)

  787 x 453 x 239  mm

• Weight

  Product with packaging (kg)

  10.63  kg

  Product with stand (kg)

  6.19  kg

  Product without stand (kg)

  4.86  kg

• Operating conditions

  Altitude

  Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

  Temperature range (operation)

  0°C to 40  °C

  Relative humidity

  20%-80  %

  Temperature range (storage)

  -20°C to 60  °C

  MTBF (demonstrated)

  Display 1: 70,000 hrs (excluded backlight)

• Sustainability

  Environmental and energy

  RoHS

  Post consumer recycled plastic

  85%

  Recyclable packaging material

  100  %

  Specific Substances

  • Mercury free

  • PVC / BFR free housing

• Compliance and standards

  Regulatory Approvals

  • CB

  • CCC

  • CE Mark

  • FCC Class B

  • ICES-003

• Cabinet

  Finish

  Texture

  Foot

  Black

  Front bezel

  Black

  Rear cover

  Black
